10kv 200kva Single Phases Power Distribution Transformer

We are offering 10kv 200kva Single Phases Power Distribution Transformer.
10kv 200kva single phases power distribution transformer
specifications
1,iso9001 ctqc
2.all copper
3.low loss, low noise,
4.high reliability strong short-circuit impedance
10kv 200kva three-phases power distribution transformer applies new type insulating structure and makes short-circuit impedance strong. the iron core is make up of cold-rolled silicon-steel plate of high quality. high winding group is made up of high quality oxygen-free copper liner lines and it adopts multilayered drum type structure. all fasteners have been processed with special treatment to prevent them from loosening.
as high-tech product that promoted by the country, the product has many advantages as high efficiency, low loss, its social benefits are remarkable that will save much electricity consumption and operating cost.
rated
capacity
kva voltage connection
kv vector
group loss
(kw) no-load current
% short circuit
% weight (kg) external dimension
mm
l*b*h
hv lv no load load machine oil total
30
10
10.5
11
â±5% 0.4 dyn11
yyn0 0.10 0.60 1.4 4.0 170 70 310 750*500*950
50 0.13 0.87 1.4 230 80 400 850*520*1000
63 0.15 1.04 1.2 270 100 460 900*550*1010
80 0.18 1.25 1.2 320 110 540 900*600*1060
100 0.20 1.50 1.1 370 120 600 900*610*1150
125 0.24 1.80 1.0 410 130 660 950*620*1150
160 0.28 2.20 1.0 470 140 760 980*710*1180
200 0.34 2.60 0.9 540 150 870 1000*750*1200
250 0.40 3.05 0.8 630 160 1010 1050*800*1250
315 0.48 3.65 0.8 820 230 1280 1100*840*1350
400 0.57 4.30 0.7 980 250 1450 1150*870*1450
500 0.68 5.15 0.7 1160 300 1780 1200*970*1500
630 0.81 6.20 0.7 4.5 1400 340 2120 1250*1050*1500
800 0.98 7.50 0.7 1800 450 2730 2200*900*2100
1000 1.15 10.30 0.6 2000 530 3130 2250*1100*2200
1250 1.36 12.00 0.5 2350 600 3620 2350*1150*2250
1600 1.64 14.50 0.5 2910 720 4460 2350*1750*2350
2000 1.96 17.80 0.4 5 3480 830 5300 2520*1920*2550
2500 2.28 20.50 0.4 5.5 4030 1090 6300 2550*2250*2550.
