12 Pin Male Sensor Shielded Underwater T Cable Connector

12 pin male and female sensor shielded underwater ip67 ip68 protection class t cable connector
• m12 circular connector according to iec 61076-2-104
• m12 circular connector with m12*1.0 screw locking
• equivalent to binder, phoenix, lumburger automation..
• waterproof rating is ip67ip68, protected from dust and water during immersion, resistant to many oils and chemical
generally description:
connector series: m12
standard: iec 61076-2-104
coding: a
gender: male and female
connector design: cable plug
connector locking system: fix screw
waterproof rating: ip67ip68
normal temperature: -10℃~+80℃
material:
connector body: tpu
male contacts: brass with gold plated
female contacts: phosphorus copper with gold plated
screwnut: brass with nickel plated
waterproof 0-ring: fkm
electrical data:
contact resistance: ≤5mω
insulation resistance: ≥100mω
rated current: 3a~1a
rated voltage: 60v~30v
