13h/f Series Control Valve

We are offering 13h/f series control valve.
Outline
the 13hf series three-way convergingdiverging control valve adopts the top guided pressure unbalanced plug. It is mainly used for converging or diverging media of several flow channels. Entering from two channels and exiting from one channel is called three-way converging, and conversely, entering from one channel and exiting from three-way valve can also play the pipe shut-off and opening function. The standard convergingdiverging design is the unbalanced double- seat trim structure. In addition, special cages with noise reduction and anti-cavitation functions can also be designed according to the service conditions.
parameters of control valves
dn 25~300mm
pn class150~600
applicable temperature range -196℃～560℃
trim features double-seat sleeve guided
body type three-way type
bonnet type standard type, heat dissipation type, cryogenic type, bellows
flow characteristic equal percentage, linear, quick open
shut-off class as me b16.104 iv (standard metal seat)
pipe connection type flange type, butt welding type
actuator type pneumatic diaphragm actuator
pneumatic piston actuator
electric actuator.
