16channel H.264 CCTV DVR

Features:
1) H.264 video compression
2) Support Mobile Phone Surveillance
3) Support Email alarm, PTZ
4) Multiplex operation: Live display, recording, network transmission, recording, backup,mobile phone surveillance simultaneously
5) Recording frame rate,PAL: 25fps NTSC:30fps
6) Support mouse, remoter controller, panel operating
Detailed Specification
Operating system
LINUX OS
Video compression format
Main profile H.264
Video input
16 channels BNC
Video output
1 channel BNC
Audio input
8 channels RCA
Audio output
1 channel RCA
Multiplex operation
Live display, recording, network transmission, recording, backup,mobile phone surveillance simultaneously
Display resolution
PAL:D1(704*576),NTSC:D1(704*480)
Recording mode
Timer/manual/motion detection/alarm
Recording frame rate
PAL:25fps NTSC:30fps
Recording quality
High, normal, low
Recording resolution
CIF
Recording playback
1/4/8/16 channel playback simultaneously
Recording backup
Support USB disk backup, moved hard disk backup, network backup, backup by files, backup by time
Recording display
Special player, support AVI file format conversion
Email alarm
Send pictures to the designated Email
PTZ
Support
PTZ protocol
PELCO-D,PELCO-P
HDD
Support 2 SATA HDD ,capacity to 4T
HDD remain time hint
Support
Network and protocol
1 RJ-45 10/100M via Ethernet, support TCP/IP,DHCP,UPNP,DNS,DDNS,NTP etc.
IE browser
Support
Client software
Support
Dual stream
Support(main and secondary interchange)
Multi-language
Support
Mobile phone surveillance
Support Windows, symbian, iPhone, blackberry, Android operation systems
Mouse interface
USB1.1
Backup interface
USB2.0
Remote controller
Support(Support controller ID matching)
User authority
Support multi-level user authority distribution
Power
DC12V/3A
Working temperature
0°C-50°C
Working humidity
10%-90%
