2 Layer Microwave PCB

Microwave pcb  is a type of pcb designed to operate on signals in the megahertz to gigahertz frequency ranges (medium frequency to extremely high frequency).bare copper pcb,white solder microwave pcb.whatever you need normal fr4,high tg ,aluminum board,rf board with low er,ptfe(teflon),heavy copper.large board,high tech board with blind/burried vias.impedence control boards.we can offer such products in quick turn as we have many different material in stock. Pcb features: 1.layer: 22.material: copper base3.thickness: 1.6mm4.copper: 1oz5.mini hole: 0.15mm6.mini width/space: 0.3mm/0.3mm7.finish: immersion goldour manufacturing capability:manufacture capability layers: 1-32 layersmaterials: cem1, cem3, teflon, rogers, fr-4, high tg fr-4, aluminum base, halogen freemax board size: 510*1200mmmaterial: rohs directive-compliantpcb thickness: 1.6mm-6.4mmout layer copper thickness: 1-6ozinner layer copper thickness: 1oz-12ozmax board thickness: 6.0mmminimum hole size: 0.150mmminimum line width/space: 3/3milmin s/m pitch: 0.1mm (4mil)plate thickness and aperture ratio: 12:1minimum hole copper: 20μmhole diameter tolerance (pth): ±0.075mm (3mil)hole diameter tolerance (npth): ±0.05mm (2mil)hole position deviation: ±0.05mm (2mil)outline tolerance: ±0.05mm (2mil)surface finish: hasl leadfree, immersion enig, chem tin, flash gold, osp, gold finger, peelable, immersion silver,enepigsolder mask: green/blue/red/black,purple,white,yellow,transparent legend:
