200T-A Hydraulic Tablet Press

200T-A Hydraulic tablet press
Applications: Model 200T-A, 200T-B and 200T-C are in same operation way. All of them are adjusted from 100T hydraulic tablet press machine. Those machines are popularly used in production of disinfectants, mothballs, detergents, food, glass tablet, ceramic, magnetic tablets, and bath salt tablets and so on.
Model features: 200T-A Hydraulic tablet press in stainless steel configuration
*Its surface is made of high quality stainless steel material so that can prevent it from rust or corrosion damage in production process.
*It treats the hydraulic system which purchased from Taiwan as core and runs stably.
*It can produce 200g, 300g, 400g, 500g TCCA tablets (Trichloroisocyanuric acid tablet).
*Its mould is made of titanium material.
With a professional technical team, we can manufacture the machine according to you.
Technical Parameters: 200T-A Hydraulic tablet press are controlled by the PLC program and time can be adjusted following the production. It runs automatically and also can be controlled manually. All operations can be adjusted into the best state through PLC. So the machine is easy to be operated and work stably, safely and accurately.
The hydraulic components are equipped inside of machine, which can keep it out from the damage from outside. The control panel can be designed into any languages.
Model 200T-A Hydraulic tablet press
Working pressure 2000 KN
Max diameter of down mould 650 mm
Max length of upper mould 270 mm
Depth of fill 300 mm
Max diameter of tablet 650 mm
Production capacity 6-10 times per minute
Motor 15 KW
