Electric 100-1000kg Milling Machines Retailer in Ludhiana Punjab India

Electric 100-1000kg Milling Machines, Voltage : 220V

Sold By : Industrial Machinery Corporation

Product Specifications

Driven TypeElectric
Machine Weight100-1000kg
Operating ModeAutomatic
Power1-3kw
Country of Origin220V
Total Carbohydrate1year
Supply TypeManufacturer, Exporter, Supplier, Retailer

Preferred Buyer From : All over the world

Product Overview

Industrial Machinery Corporation are Milling Machine Manufacturer , Exporters and supplier. These Milling Machines are made from very high quality raw material which ensures hassle free work performance at its user end. These Milling Machines are widely finds its applications in various industrial sectors.

Standard Accessories : Vertical Attachment

Optional Accessories

Electric Motor
Starter
Belts
Coolant Pump
Dividing Head
Rotary Table
Slotting Attachment

Specifications:
Model	ML -7″	ML – 8.5″	ML – 10″	ML – 11″	ML – 12″‘	ML – 13.5″
Face of Bed	7″	6′	7′	9′	10′	12′
Surface of Table	30″ x 7″	42″ x 9″	48″ x 10″	52″ x11″	54″ x 12″	64″ x 14″
No. of Tee Slots	3	3	3	3	3	3
Swivel either side of centre	45o	45o	45o	45o	45o	45o
Cross Travel	6″	7″	8″	10″	12″	15″
Vertical of Travel	13″	15″	16″	22″	26″	32″
Longitudinal Travel	15″	21″	24″	26″	27″	32″
Standard Arbor	1″	1″	1″	1″	1″	1″
Taper of Spindle	M.T. 3	M.T. 3	I.S.O. 40	I.S.O. 40	I.S.O. 40	I.S.O. 40
No. of Spindle Speed	3 & 6	6	6	9	9	9
Range of Spindle Speed	34 to 650	51 to 715	51 to 715	50 to 550	50 to 550	45 to 475
Dia of Spindle	2″	2″	2″	3″	3″	4″
No. of Longitudinal Feeds	2	2	3	3	3	3
Motor Required	1 H.P.	2 H.P.	2 H.P.	2 H.P.	3 H.P.	5 H.P.

Specifications
Model	MML -7″	MML – 8.5″	MML – 10″
Face of Body	7″	6′	7′
Surface of Table	30″ x 7″	42″ x 9″	48″ x 10″
No. of Tee Slots	3	3	3
Swivel either side of centre	45o	45o	45o
Cross Travel	6″	7″	8″
Vertical of Travel	13″	15″	16″
Longitudinal Travel	15″	21″	24″
Standard Arbor	1″	1″	1″
Taper of Spindle	M.T. 3	M.T. 3	I.S.O. 40
No. of Spindle Speed	3 & 6	6	6
Range of Spindle Speed	34 to 650	51 to 715	51 to 715
Dia of Spindle	2″	2″	2″
No. of Longitudinal Feeds	2	2	3
Motor Required	1 H.P.	2 H.P.	2 H.P.
POWER FEEDS
Range of 3 Cross Feeds	28 – 75 P/M	19 – 63 P/M	19 -63 P/M
Range of 3 Verticals Feeds	6 – 12 P/M	6 – 12 P/M	6 – 12 P/M
Range of 3 Longitudinal Feeds	28 – 75 P/M	19 – -51 P/M	19 – 51 P/M
Rapid Longitudinal & Cross	1200 P/M	1066 P/M	1066 P/M
Rapid Vertical	220 P/M	254 P/M	254 P/M
Feed Motor	2 H.P. 960 RPM	3 H.P. 960 RPM	5 H.P. 960 RPM
Coolant Pump	1/10 H.P.	1/10 H.P.	1/10 H.P.
