Features :
| Model | SCM800 | SCM900 | SCM1000 | SCM1250 | SCM1680 |
| Working diameter (mm) | Φ800 | Φ900 | Φ1000 | Φ1250 | Φ1680 |
| Max feed size (mm) | ≤20 | ≤20 | ≤20 | ≤20 | ≤20 |
| Final size (mesh) | 325-2500 | 325-2500 | 325-2500 | 325-2500 | 325-2500 |
| Output (kgh) | 500-4500 | 800-6500 | 1000-8500 | 2500-14000 | 5000-25000 |
| Model | SCM800 | SCM900 | SCM1000 | SCM1250 | SCM1680 | |
| Main motor | Power | 75 | 45×2 | 132 | 185 | 315 |
| Analytical engine (FM motor) | Power | 18.5 | 18.5 | 30 | 15x4 | 18.5×5 |
| Blower motor | Power | 45 | 55 | 75 | 55×2 | 90×2 |
| Crusher | Model | PC400×600 | PC400×600 | PC400×600 | PC600×800 | PC600×800 |
| Power | 18.5 | 18.5 | 18.5 | 45 | 45 | |
| Elevator | Model | TH-200 | TH-200 | TH-300 | TH-300 | TH-300 |
| Power | 3 | 3 | 4 | 5.5 | 7.5 | |
| Vibrating feeder | Model | 300×60×1.8 Φ159-1.8 | 300×60×1.8 Φ159-1.8 | 300×60×1.8 Φ159-1.8 | 400×80×2 Φ219-2 | 400×80×2.8 |
| Power | 1.5/3 | 1.5/3 | 1.5/3 | 1.5/3 | 2.2 | |
| Discharge screw conveyor | Model | LS219-4.5/LS219-3 | LS219-5.8 | LS219-6.9/LS219-5 | LS219-5 | LS273-8.6 |
| Power | 3 | 3 | 4 | 3×2 | 5.5×2 | |
| Discharge valve | Model | ZJD-200 | ZJD-200 ZJD-250 |
ZJD-200 ZJD-250 |
ZJD-250 | ZJD-300 ZJD-200 |
| Power | 0.75 | 0.75 + 1.1 | 0.75+ 1.1 | 1.1 | 1.5+0.75 | |
| Pulse dust collectors | Model | DMC120/DMC16 | DMC16 | LDMC25 | LDMC45 | LDMC400×2 |
| Air compressor | Model | KSH150D/LG1.5-8 | KSH240D/LG2.4-8 | KSH300D/LG3.6-8 | LG6.2-8 | LG10-8 |
| Power | 11 | 15 | 22 | 37 | 55 | |
