It's suitable for an extremely wide range of applications,Including :Mobile Devices, Set-top-box,ADSL,Audio&Video product,Household appliance,Charger, laptopnotebook power adaptor, CCTV AC adaptor, HDD adaptor, Digital frame power adaptor.
INPUT:
Input Voltage: 90~264VAC
Frequency: 47-5060-63hz
Input Current: 0.15A(Max) 100240VAC
Inrush Current: 15A Max 120VAC at max load
30AMax 240VAC at max load
Leakage Current: 0.25mA Max
OUTPUT:
Output Voltage: 18VDC Max
Output Current: 0.7A Max
Full complies with CEC Level V, MEPS V, EUP 2011
Over voltage protection
Over current protection
At 110~200% of lo and Auto-recovery
Electronic short circuit protection
Operating temperature 0~40°C free convection
Operating humidity 10-90% RH Non Condensing
Sea level Non-operating temperature -20~80°C
Safety Standards
Information technology equipment
IECEN60950-1,UL60950-1,CSA C22.2 No.60950-1-03,BG4943
Certificates and Approvals:
CB,GS,CE,UK,TUV,UL,CCC,FCC,PSE, C-TICK
EMI Emission
Radiation Test & Conduction Test: EN55022FCC Part 15.
Harmonic Test: EN61000-3-2
Flicker Test: EN61000-3-3
EMS Immunity:
ESD Test: EN61000-4-2
RS Test: EN61000-4-3
EFT Test: EN61000-4-4
Surge Test: EN61000-4-5
CS Test: EN61000-4-6
