3 PHASE DIGITAL AMMETERS & VOLTMETER

Max Overload1.2 XVin. (continous). 2x Iin. (continous).
Display14.2mm (0.56"")height
Max. Rel. Humidity< 95 %
Dielectric StrengthAC 2 KV for 1 min. Between Input and Power terminals. AC 3 KV for 1 min. all terminals to case.
Supply TypeManufacturer, Exporter, Supplier, Retailer
Preferred Buyer Location All over the world

Product Details

Dielectric StrengthAC 2 KV for 1 min. Between Input and Power terminals. AC 3 KV for 1 min. all terminals to case.
Power Consumption< 5VA.
Storage Temp-10° - 70° C.
Max. Rel. Humidity< 95 %
Sampling timeAbout 0.4 Sec. Typically.
Max Overload1.2 XVin. (continous). 2x Iin. (continous).
Aux. SupplyAC (230V or 110V) ± 10%, 50 / 60 Hz DC Voltage on Request
Display14.2mm (0.56"")height
Operating Temperature0° - 50° C

3½ DIGIT BRIGHT RED LED DISPLAY
AUTO SCROLLING TO DISPLAY THREE PHASE CURRENT, VOLTAGE
HOLD TO DISPLAY INDIVIDUAL PHASE
GLOWING LED INDICATES PHASE BEING MEASURED R-Y-B, RY-YB-BR.
RESCALEABLE CURRENT RANGES WITH DECIMAL POINT SELECT
DIN STANDARD SIZE 96 X 96mm.
