automated and manual fine pitch smt;
multi-layer printed circuit boards, flex boards;
bga with x-ray and rework capability;
rohs directive-compliant lead-free assembly;
wave soldering, conformal coating;
in circuit testing, functional testing;
in-line aoi inspection system;
xray inspection aoi test;
1. Bom lists and pcb gerber files;
2. Clear picture of pcba or samples for us;
3. Test method required;
se | item | capability |
1 | cbase material | fr-4, high tg fr-4 , halogen free material ,cem-3,cem-1,ptfe,rogers ,arlon ,taconic,aluminum base,teflon,pi ,etc |
2 | layers | 1-40 ( ≥30 layers needs review ) |
3 | finished inner/outer copper thickness | 0.5-6oz |
4 | finished board thickness | 0.2-7.0mm(≤0.2mm needs review),≤0.4mm for hasl board thickness≤1.0mm: +/-0.1mm 12.0mm: +/-8% |
5 | max panel size | ≤2sidespcb: 600*1500mm multilayer pcb: 500*1200mm |
6 | min conductor line width/spacing | inner layers: ≥3/3mil outer layers: ≥3.5/3.5mil |
7 | min welding ring | 4mil |
8 | hole tolerance | pth: +/-3mil;npth: +/-2mil |
9 | outline profile | rout/ v-cut/ bridge/ stamp hole |
10 | solder mask color | green,yellow,black,blue,red,white,matte green |
11 | component mark color | white,yellow,black |
