32'' LCD S580 Car Wheel Alignment Machine

We offer 32'' Lcd S580 Car Wheel Alignment machine.
Outstanding functions
★ During operating, the cameras track the position of the vehicle and adjust to the corresponding height automatically.
★ 3D Measurement: The 3D measurement technics which is based on real running surface of wheels, is more specific and precise.
★ Shooting System: Composed of high-performance cameras and four targets disks, the camera system can measure the vehicle's running posture vividly.
★ Target Disk: The solid-state target disks made of special materials and sturdy and durable without eletronic components.
★ Pushing Measurement: None of any wheel compensation is needed. Only one pushing can complete the measurement.
★ 3D Max System: The unique visual 3D max dynamic measurement system is real and vivid.
★ Calibration System: Only one calibration is needed after the initial installation without any repetitive calibration following.
Other Features
♦3D max Dynamic Display System
♦No Electronic Components
♦Four-point Wheel Clamps
♦3D Animation Technics
♦Reminding Window
♦Pre-Tightening Rotatable Jaw
♦Pushing the Vehicle Once
♦3D Animation Adjustment Guidance
♦Animation Operation Reminding
♦Original Standard Database
♦Caster and Kingpin Inclination Measurement
♦Body Dimension Measurement
♦Toe-out-on Turn Measurement
♦Tire Diameter Measurement
♦Maximum Turning Angle Measurement
Technical parameters
Item Accuracy Measurement Range
Display Precision 1’
Camber ±2' ±15°
Caster ±2' ±26°
Kingpin Inclination ±2' ±26°
Toe ±2' ±20°
Setback ±2' ±5°
Thrust Angle ±2' ±5°
