Introduction to the 3200mm Kraft Paper Machine
Material: waste paper， Raw Pulp,Inferior Cotton,Wood,Straw,Wheat Straw Hood ,Bamboo
Papermaking Products:Kraft paper ,Corrugated paper
Output Weight: 100-250g/ m²
Daily Capacity : 30-35t/d
Tirm Width: 3200mm
Speed: 80-150m/min
Cylinder Mould: 3750mm
Track Gauge: 4300mm
Drive way: Alternating current frequency conversion ,section drive
The main Section :
Cylinder Section: Cylinder Mould :1500 mm×3750mm, Couch Roll :500×3750mm Rubber Hardness Shore 38°C±2
Press Section: Marble Roller 800 mm×3750mm, Rubber Roll 750 mm×3750mm,Rubber Hardness Shore 90°C±2,Pneumatic Pressure Device.
Dry Sction: Dryer 2500mmx3750mm and 500mm×3750mm , Roller 750 mm×3750mm, Rubber Hardness Shore 90°C±2, Pneumatic Pressure Device, Opposite Pressurized Roll , Rubber Hardness shore 90°C±2
