35kv 3000pf High Voltage Capacitor

CT81 HV Disc Ceramic Capacitor 2KV~50KV, 10pf~50000pf
CT81 High Voltage Disc Ceramic Capacitor, High Voltage Disk Ceramic Capacitor, HV disc ceramic capacitor, 20KV radial disc ceramic capacitor, 30kv axial ceramic capacitor, 50kv axial disc ceramic capacitor
Manufacture Supply CT81 High Voltage Ceramic Capacitors
Application,
CO2 lasers
High voltage pulse generator
X-ray power supply
X-ray high voltage generator
NDT (Non-destructive testing)
Airport security equipment
High frequency & high voltage power supplies
Medical power supply
Military
Rated Voltage: 1000V, 2000V, 3000V, 4000V, 5KV, 6kv, 6.3KV, 8KV, 10KV, 12kv, 15KV, 20KV, 25KV, 27kv, 30KV, 35KV, 40KV, 50KV
Capacitance: 100pf (101), 120pf (121), 200pf (201), 220pf (221), 270pf (271), 330pf (331), 390pf (391), 470pf (471), 500pf (501), 510pf (511), 560pf (561), 680pf (681), 750pf (751), 1000pf (102), 1200pf (122), 1500pf (152), 2000pf (202), 2200pf (222), 2700pf (272), 3000pf (302), 3300pf (332), 3500pf (352), 4000pf (402), 4500pf (452), 4700pf (472), 5600pf (562), 6000pf (602), 6800pf (682), 10nf (103), 20nf (203), 22nf (223), 47nf (473)
Characteristics:
Operating Temperature Range: -25C to +85C
Rated Voltage (V): 1 KV -50KVDC
Capacitance Range: 100pF -50,000pF
Temperature characteristic: N4700(DL), UJ, SL, YL, BN,Y5P, Y5R, X7E(X7E), X7F(X), X7R(X7R), Y5S(S), Y5T(D), Y5U(E), Y5V(F)
Test Voltage: 2 times of the rated voltage.
Dissipation Factor (tan): at 1 KHz, 1+-0.2 Vrms, 25C
Y5P, Z5U: tan
