| Particulars | RPB-1 | RPB-2 | RPB-3 | RPB-4 | RPB-5 | RPB-6 | RPB-7 | RPB-8 | RPB-9 | RPB-10 |
|---|---|---|---|---|---|---|---|---|---|---|
| Capacity in Tons | 20 | 25 | 65 | 80 | 100 | 100 | 120 | 140 | 160 | 200 |
| Bending Cap. Length X Thickness | 1525x1.6 | 2030x1.6 | 2030x4 | 2540x3.25 | 2540x4.5 | 3125x3.25 | 2540x8 | 2030x8 | 3125x6 | 3125x8 |
| Dist. Between Housing | 1120 | 1220 | 1220 | 1700 | 1700 | 1700 | 1700 | 1420 | 1900 | 1900 |
| Stroke Length | 50 | 50 | 76 | 76 | 76 | 76 | 76 | 76 | 76 | 76 |
| Stroke Per Minute | 32 | 32 | 32 | 32 | 30 | 32 | 30 | 30 | 30 | 3 |
| 0Ram Adjustment | 25 | 25 | 40 | 40 | 40 | 40 | 40 | 40 | 40 | 40 |
| Shut Height Ram Stroke DW | 200 | 200 | 250 | 250 | 275 | 275 | 275 | 275 | 275 | 300 |
| Table Height | 760 | 760 | 800 | 800 | 800 | 900 | 900 | 900 | 900 | 900 |
| Depth of Throat | 250 | 250 | 275 | 275 | 275 | 275 | 300 | 350 | 350 | 350 |
| Main Motor HP | 5 | 7.5 | 7.5 | 10 | 15 | 15 | 20 | 25 | 25 | 30 |
| Ram Adjustment Motor HP | Manual | 1 | 1 | 1.5 | 2 | 2 | 2 | 2 | 2 | 2 |
| Dia Space Length x Width | 1525x125 | 2030x150 | 2030x200 | 2540x200 | 2540x254 | 3125x200 | 2540x254 | 2030x254 | 3125x254 | 3125x254 |
| Machine Length (LxR) | 1800 | 2300 | 2300 | 3050 | 3050 | 3250 | 3250 | 2600 | 3300 | 3300 |
| Machine Width (FxB) | 1100 | 1100 | 1100 | 1600 | 1600 | 1750 | 1750 | 2160 | 1850 | 1850 |
| Machine Height | 2150 | 2300 | 2300 | 2600 | 2600 | 3000 | 3100 | 3200 | 3200 | 3200 |
| Weight Approx | 2150 | 2450 | 3300 | 5500 | 6900 | 7800 | 8300 | 6500 | 9400 | 12500 |
