3D Leather Embossing Machine, Brand Name : Tengcang

 3d leather wall panel machine
3d leather wall machine
machine parameters
power: 18kw
dimensions: 2200 * 700 * 1900mm
maximum stroke of movable beam: 250mm
working speed: piece10s
backing velocity: 50 mms
nominal pressure: 630kn
maximum working pressure of liquid: 25mpa
voltage: 380v
weight: 1600kg
machine characteristics
1, precise four-column guide design ensured high precision of products.
2, use large-diameter hydraulic cylinders, high presser and stable operation.
3, use resisting high temperature motors, ensuring safe and long-term service.
4, made by high-precision and high-strength thick steel,deformation and rigidity.
5, optimization design, simple, economic and applicable. Direction valve integrated system hydraulic control system, reliable, long life, small hydraulic impact, reduce the link pip and leak. Independent electrical control system, reliable, operating convenience, centralized control buttons, support manual and automatic function.
6, up and down heating form, adjustable temperature,make product texture more clearly.
