40uf 220v,AC Motor Capacitor Cbb65

We 40uF 220V,AC motor capacitor CBB65.
Feature :
1.High insulation resistance,small warm up inside.
2.Good capacitance stability and self-healing.
3.Our price are very competitive in the market.
4.we also can according to your drawing and samples to do it.
5.small size and light weight.
6.widely used in DC and pluse circuits of TVs and various electronic equipment.
Specification:
Working Temperature Range climate types:  408521
Rated Voltage Range :110Vac,250Vac, 300Vac, 370Vac, 440Vac ,450vac,480vac,500vac,550vac,600vac,630vac
Rated Capacitance Range 2-120uF
Dissipation Factor Tan ≤ 0.002
Rated Tolerance of capacitance 5% 10%
Testing Voltage between leading-out ends: 1.75UR 5S or 2UR 2S no break down
Insulation resistance between leading-out ends: 3000
Nominal capacitance(uF):
2,3,4,5,7.5,10,12.5,15,17,20,22.5,25,30,35,40,45,50,55,60,70,80,100,120, 25+5, 30+5, 35+5, 50+5, 60+5, 70+5, 80+5,100,uf,MFD,microfarad.

Product type CBB65 35uF capacitor
Capacitance range 3~120uF
Capacitance tolerance +-5% or according to customes request
Rated vottage 200VAC 250VAC 300VAC 370VAC 400VAC 440VAC 450VAC 500VAC 600VAC 630VAC
Rated frequency 50 60 Hz
Operating temperature -40~+70+85
Safety protection P1 P2
Testing voltage T-T:2.0 Un60s
Operating life class B classC
Insulation resistance >=3000s
Standard IEC60252 GBT3667-2008
sk capacitor  super capacitor 2.7v 350f CBB65 by ISO9000 approved
Capacitor CBB66CBB65CBB60CBB61 AC metallized polypropylene film Capacitor
CBB series  technology  information

Model CBB65 CBB60 CBB61
Material Metallized polypropylene Metallized polypropylene Metallized polypropylene
Filling Oil Oil Resion Resion
Can Matel PlasticMatel Plastic
Capacitance range 3~120uF 4~30uF 1~16uF
Voltage range 200~630VAC 200~630VAC 200~630VAC
Security level P1P2 P0 P0
Operating temperature -40~+70+85 -40~+70+85 -40~+70+85
