Customers should stay rest assured with us for the payment procedures. They can pay us conveniently through wide-ranging payment mediums. We are a quality-conscious firm and make use of high-grade packaging material for wrapping products. Also, we have installed modern packaging machines that assist us in meeting tailored packaging requirements.
| Input voltage | 180-260 V with no noticeable light fluctuation. |
|---|---|
| Expected Input | 50 HZ +/-allowable tolerance tolerance |
| Power Factor | .09 or leading |
| LED efficiency | Total Lumen - 4800 |
| Luminary efficiency | 0.7 |
| Beam Angle | 120 degree |
| Total Harmonic Distortion | Less than 20 % |
| Working Temperature | -5 To + 50 degree |
| Wattage max | 40 watt +- 5 % |
| Working Humidity | 10% - 90% RH ( preferably Hermetically sealed unit.) |
| I P Protection Level | IP-65 class protection, with covered toughened clear glass |
| UV stabilised acrylic, sealed with silicone gaskets. | |
| Lamp Casing | Powder coated , Cast Aluminum alloy |
| Life | 35000 |
| LED Type | Edison/ Everlite |
| Color temperature | 6500 K |
| CRI | 75 |
| TJ | Should be minimum to ensure a minimum life of 50,000hours, |
| L70 life as per LED manufacturers datasheet. | |
| Electrical Connector | Lead wire with minimum 1 meter long |
| Environment considerations | Environment friendly and 100% green |
| Modular design required | LED modules should be easily replaceable |
| Thermal management | Heat sink temperature to not exceed max 15 degrees |
| centigrade above ambient. | |
| Enclosure | EX D as per IS 2148 |
| Area classification | Gas plant, Oil refinery, Paint shop, |
| Transparent part | Heat resistance clear glass |
| Weight | 5 KG +-10 % |
| Dimension | Dia -250 MM Height -185 MM +- 5 % |
