Technical parameters:
model wsi1010-24 wsi1010-48
rated output capacity 1kva
rated solar power 1kw
rated battery voltage 24 vdc 48vdc
battery floating charge voltage 30 vdc 60 vdc
over voltage shutoff 34 vdc 68 vdc
over voltage recovery 33 vdc 66 vdc
under voltage shutoff 21 vdc 42 vdc
under voltage recovery 24 vdc 48 vdc
no load loss 0.6a 0.35a
output wave form pure sine wave
display mode lcd
display parameters battery voltage, charging current, status parameters
cooling mode fan
rated output voltage 110/120/220/230/240vac
wave distortion ≤4％
output frequency 50/60 hz±0.05hz
overload capacity 120% 1min, 150% 10s
inverter efficiency maximum 90%
noise（1m） ≤40db
insulating strength 1500vac,1 min
protection function solar reverse charge protection, solar reverse connection protection,
battery over charge protection ,battery over discharge protection,
battery reverse connection protection, lightning protection , output overload protection, output short circuit protection, overheating protection
working ambient temperature -20～50℃
working altitude ≤4000m
working ambient humidity 0~90%, no condensing.
