Contact SupplierWe are offering electrical
model dt-pa698-2700-9-2a
frequency range 698-9601710--2700mhz
gain 89*2dbi
beamwidth h: 79±5° , e: 68±5°
vswr ≤1.8
polarization vertical and horizontal or ±45°
fb ratio ≥13db
isolation ≥25db
max power 100w
nominal impedance 50ω
lightning protection dc ground
mechanical
connector n female*2 or customized
antenna dimension 280*180*60mm
weight 0.75kg
radome material waterproof abs
working temperature -40℃~﹢65℃
antenna color white.
