8 Color Manual T-shirt Screen Printing Machine

8 color manual t-shirt screen printing machine with a small oven
function:
registration and off-contact system
1.u-slot guide locator system
2.precise four-point pallet height adjustable system, offering wide range of off-contact adjustment
3.print head lock-in design maintains exact color-to-color repeatability but ensuring +-0.10mm registration
screen clamps & holders
1.built with a low profile and release height adjustable arms, reducing operators fatigue and downtime
2.three large-size knobs secure screen frame tightly
3.appliable in various frame sizes up to 500mm wide
4.two-spring hinge system increases the print speed
pallet system
1.special resin made pallets provide a durable, effective print surface
2.accommodate all types of pallets adhesives
3.easy-to-install feature combined with left-and-right adjustment
4.available in any special requirements
heavy duty construction
1.tapered roller bearings designed for easy spinning
2.duo-deck system speeds up print production
3.unique cabinet base support provides absolute stability and a spare space for multi-use
4.heavy duty frame construction for durability and minimum flex
models and business opportunity
1.print production made up to 700 pcshour
2.unlimited growth opportunity
3.requires no special skill or education-easily operated by anyone
technical parameter:
1. Printing colors:8colors
2. Max.printing area:400*350mm
3. Worktable area:500*400mm
4.each movable dryer power:6kw
5.size:280ã�280ã�135cm
6.weight:360kg.
