ABB Siemens Induction Motor

We are offering our customers an excellent quality range of Motors. These Motors are made from very high quality raw material which ensures high durability at its user end.

These Motors are in high demand in the market. Different sizes and designs are easily available in the market.Motors are available at most competitive prices and best delivery options.

It is among the world’s leading manufacturers of low voltage induction motors, with over many years of experience.

supplies a wide range of AC and DC motors across voltage ranges. motors offer unmatched quality and reliability,

superior technology, faster delivery and above all ‘value’ for money. So when you decide to go in for a motor -

buy once, buy the best!Type: 3-phase squirrel cage induction motors

Power Output: 0.18 to 710 kW; 0.25hp to 950 hp, according to IS:325 / IEC 600034 standards

Frame size: 71 to 400

Voltage: 415V; 220V, 440V, 460V, 690V

Frequence: 50Hz; 25 - 60Hz

Duty: S1 - S8

Ambient temp: -20°C to 70°C

Insulation: Class B / Class F / Class H

Main dimensions:

Foot mounted according to IS:1231 standards

Flange mounted according to IS:2223 standards

Enclosures:

Totally Enclosed Fan Cooled (TEFC)

Totally Enclosed Surface Cooled (TESC)

Screen Protected Drip Proof (SPDP)

Totally Enclosed Forced Cooled (TEFC)

Cooling:

IC 411 (TEFC)

IC 00 41 (TESC)

IC 01 (SPDP)

IC 416 (TEFC)

Heavy duty design

The electrical and mechanical design of ABB motors offers the highest levels of performance values in all mounting arrangements, protection class and applications.Insulation scheme

low voltage motors have a unique polyamide based class ‘F’ insulation, rated for 155°C with temperature rise limited to class ‘B’ offering high electrical and mechanical stability.

Winding Motors are wound using high quality round enameled wires conforming to IS:13730 standards. To ensure long life, the stators are impregnated with a solventless resin resulting

in good thermal conductivity and high mechanical strength.

Ventilation

Ventilation circuit has been optimally designed based on aerodynamic and acoustic considerations.Frequency converter drive

motors are suitable for operation with variable frequency drives for a specified speed range requiring minimal changes.

Low noise levels

motors are designed to minimise electromagnetic, airborne and structural noise.Enclosure Motor housings are provided with deep longitudinal fins designed to give maximum cooling

surface area. Integrated feet ensure that the frames are rigid and vibration resistant.

Installation flexibility

Dual mounting holes are provided for installation flexibility.Polyurethane (UP) paint motors are painted with PU paint, which provide protection against corrosion and also gives

the motors an excellent finish.

client recommended color are also accepted on demand at extra cost

Voltage range for extra versatility motors are matched to the standard voltage applicable anywhere in the world i.e. 380V 415V 440V 460V.

However, motors for 200 to 550V can also be provided on request.

Easy connection of terminal box, The design allows for flexible orientation.
