AC Repulsion Motor

This Model is the an educational model suitable for demonstrating to students the complete know of the Basics, Components, Starting methods, Wear & Tear & Maintenance of these motors packaged in small rating. Students can make connections of their own with the help of the terminations provided for study of features viz Starting methods, Speed-Torque, Effect of Phase angle, Study of Cogging/Crawling, Effect of reduced voltage, Blocked rotor test. AC Repulsion Motor.

TEFC, IP44, IC01, B3, Class-B, SI, Casting/Sheet metal body AC Repulsion Motor List of Experiments Starting by DOL Starter Starting by reduced voltage starter. Load test & No load test of machine Speed-Torque Analysis Voltage-Speed Analysis Speed reversal Efficiency Analysis Blocked rotor test Cold Resistance & Hot Resistance Motor Operation parameters Basic Overhauling.
