We are the leading manufacturer, exporter and supplier of highly reliable AC Servo Motor (110SY) from Wenling City, China. With a working temperature of 0oC – 55oC, these AC Servo Motors are available with a Safety Class of IP54 and an Insulation class – B. The AC Servo Motor comprises of 4 Pole pairs, a 17 bit Absolute encoder and an Incremental encoder line of 2500/5000PPR. These Motors come with good voltage and insulation resistance and are available in a self-cooling structure. As a reputed name in the industry we offer our clients installation services, which are handled by highly-experienced professionals.
| Model | L(mm) | L(mm) with brake |
|---|---|---|
| 110SY – M02030 | 157 | 217 |
| 110SY – M04020 | 187 | 247 |
| 110SY – M04030 | 187 | 247 |
| 110SY – M05020 | 202 | 262 |
| 110SY – M05030 | 202 | 262 |
| 110SY – M06020 | 217 | 277 |
| 110SY – M06030 | 217 | 277 |
| Motor Model | 110SY – M02030 | 110SY – M04030 | 110SY – M04030 | 110SY – M05020 | 110SY – M05030 | 110SY – M06020 | 110SY – M06030 |
|---|---|---|---|---|---|---|---|
| Rated Power (Kw) | 0.6 | 0.8 | 1.2 | 1 | 1.5 | 1.2 | 1.8 |
| Rated Current (A) | 4 | 3.2 | 5 | 4 | 5 | 4.5 | 6 |
| Rated Torque (N.m) | 2 | 4 | 4 | 5 | 5 | 6 | 6 |
| Max Torque (N.m) | 6 | 12 | 12 | 15 | 15 | 18 | 18 |
| Rated Speed (rpm) | 3000 | 2000 | 3000 | 2000 | 3000 | 2000 | 3000 |
| Max speed (rpm) | 3300 | 2300 | 3300 | 2300 | 3300 | 2300 | 3300 |
| Rotor Inertia (KG.m2) | 0.33x10-3 | 0.65x10-3 | 0.65x10-3 | 0.85x10-3 | 0.85x10-3 | 1.0x10-3 | 1.0x10-3 |
| Motor Weight (Kg) | 4.6 | 5.6 | 5.6 | 6.2 | 6.2 | 6.8 | 6.8 |
| Winding wire | U | V | W | PE | |
|---|---|---|---|---|---|
| Socket Number | 2 | 3 | 4 | 1 | |
Braking Lead | PE | Brake | Brake | ||
Socket Number | 3 | 1 | 2 | ||
Note : Brake voltage is DC 24V (Non polar requirement) | |||||
| Signal Definitions | 5V | OV | A+ | B+ | Z+ | A- | B- | Z- | U+ | V+ | W+ | U- | V- | W- | PE |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Socket Number | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 | 15 | 1 |
