Contact SupplierThe Agriculture Suction Pipe is a rugged, flexible, and weather-resistant pipe designed for suction and discharge of water, slurry, and light chemicals in agricultural operations. Made from high-grade PVC or rubber with reinforcement, it is ideal for use with pumps, tractors, and irrigation systems in farms, fields, and rural water management.
| INSIDE(mm) | INSIDE(inch) | Wall Thickness (mm) | Bending Radius (mm) | Pressure Kg/cm | Vaccum Length mH2O | Roll (m) | Volume (m |
|---|---|---|---|---|---|---|---|
| 25 | 1" | 2.8 | 130 | 5 - 15 | 7 | 30 | 0.093 |
| 32 | 1 1/4" | 3.0 | 182 | 5 - 15 | 7 | 30 | 0.130 |
| 40 | 1 1/2" | 3.4 | 182 | 5 - 15 | 7 | 30 | 0.190 |
| 50 | 2" | 4.1 | 235 | 5 - 15 | 7 | 30 | 0.329 |
| 63 | 2 1/2" | 4.2 | 290 | 5 - 15 | 7 | 30 | 0.475 |
| 76 | 3" | 4.7 | 340 | 5 - 15 | 7 | 30 | 0.676 |
| 90 | 3 1/2" | 6.0 | 420 | 4 - 12 | 7 | 30 | 0.630 |
| 100 | 4" | 6.0 | 470 | 4 - 12 | 7 | 30 | 0.765 |
| 127 | 5" | 6.2 | 680 | 3 - 9 | 5.5 | 15 | 1.200 |
| 150 | 6" | 6.2 | 780 | 3 - 9 | 5 | 15 | 1.255 |
