Contact SupplierImage Sensor 1/3” SHAP CCD
Image dimensions NTSC: 768 × 494 Pixels
PAL: 795 × 596 Pixels
Synchronization System Internal
Resolution 480 TVL
Minimum Illumination 0.4 Lux /F:2.0
Automatic Gain Control yes
Electronic Shutter Automatic, 1/50 sec.~1/100,000sec.
Backlight Compensation Automatic
Waterproof level IP67
Signal-to-noise Ratio over 48db
Video Output 1.0 Vp-p / 75 ohm composite
White Balance 3200~ 9200˚K
Power Supply Standard: 12V DC(Standard)
Power consumption 4.5 W
Lens Standard: f3.6mm/F1.2 ˚
Ootional: f6.0
Operating Temperature -55˚C ~ +50˚C
Operating Humidity Up to 100%
Dimensions 57 x 60 mm(Mini Side)
