ENGINE RATINGÂ BASELINES
Engines are rated at standard SAE J 1349 testing code. Net power rating conditions are obtained at 29.61 inches Hg (100.3 kPa) barometer (approximately 300 feet or 91.44m above sea level) and 77°F or 25°C.
A deduction of 3% from engine horsepower rating at standard SAE conditions shall be made for diesel engines for each 1000ft or 305m altitude above 300ft or 91.4m
A deduction of 1% from engine horsepower rating as corrected to standard SAE conditions shall be made for diesel engines for every 10°F or 5.6°C above °F or 25°C ambient temperature.
| FD30H | FD50H | FD80H | FD140H | FD180H | FD225H | |
|---|---|---|---|---|---|---|
| Engine Power Output | 19hp | 36hp | 50hp | 127hp | 185hp | 225hp |
| Number of Cylinders | 3 | 4 | 4 | 6 | 6 | 6 |
| Lub. Oil Pressure | 0.2 to 0.4 Mpa | 0.2 to 0.4 Mpa | 0.2 to 0.4 Mpa | 0.2 to 0.6 Mpa | 0.2 to 0.6 Mpa | 0.2 to 0.6 Mpa |
| Alternator | 12v | 12v | 12v | 24v | 24v | 24v |
| Starting Motor Voltage | 12v | 12v | 12v | 24v | 24v | 24v |
| Crankshaft Idle Speed | 750-850 rpm | 750-850 rpm | 750-850 rpm | 750-850 rpm | 1100-1200 rpm | 1100-1200 rpm |
| Thermostat Opening Temp | 82°C | 82°C | 82°C | 82°C | NA | NA |
| Rated Speed | 2900 rpm | 2900 rpm | 2900 rpm | 2900 rpm | 2900 rpm | 2900 rpm |
| Self-priming | Yes | Yes | Yes | Yes | Yes | Yes |
| Aspiration | Natural | Natural | Natural | Natural | Turbocharger | Turbocharger & After cooler |
| Engine Oil Grade | 15w 40 | 15w 40 | 15w 40 | 15w 40 | 15w 40 | 15w 40 |
