    Air Insulated Glass

    • Supply TypeManufacturer, Exporter, Supplier, Retailer
    • Preferred Buyer Location All over the world

    Two or more liters of glass are assembled and separated at a fixed interval using an aluminum spacer filled with a drying agent called desiccants to absorb the moisture within air space. The....
    View More Details
    Send Enquiry

    Company Information

    • calendar Member Since 7 Years
    • building Nature of Business Retailer

    Ask for more detail from the seller

    Contact Supplier
    Report incorrect details
    • Product Details

    • Company Details

    no_img_icon

    Two or more liters of glass are assembled and separated at a fixed interval using an aluminum spacer filled with a drying agent called desiccants to absorb the moisture within air space.
    The surrounding edges of the double glazed units are then sealed first by a primary sealant and then by secondary sealant.

     Insulated glass increases insulating properties of glass while substantially reducing condensation. This reduces load on air conditioning, reduces cost of HVAC, sound resistant and reduction in the greenhouse gases.

    Applications Architectural
    Façades, WindowsIndustrial
    Visi Coolers




    Glass Type
    Tinted glassReflective glass
    Low E glass with max emissivity k = 0.08
    Glass Thickness
    4 mm5 mm6 mm8 mm
    10 mm12 mm
    Lower thermal conductivity gas filled Double Glazed Unit (DGU)
    Krypton GasXenon GasArgon Gas
    Air Gap
    5.5 mm9.5 mm14.5 mm19.5 mm6.5 mm
    10.5 mm15.5 mm21.5 mm7.5 mm11.5 mm
    16.5 mm23.5 mm8.5 mm13.5 mm17.5 mm
    Glass size
    Minimum300mm x 300mm
    Maximum1500mm x 2000mm
    Shapes
    TriangleTrapeziumPentagon
    Type of glazing
    Doubled glazed unitTriple glazed unitStep glazing
