Technical Data:
Payload capacity                              2,400 - 3,000 kg
Speed                                             0 - 54 m/min.*
Max. lifting height                            250/400 m**
Car width (internal)Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â 2.0 m
Car length (internal)Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â 3.2 - 5.0 m
Car height (internal)Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â 2.8 m
Motor control                                  Frequency Control (FC)
No. of motors                                  3
Safety device type                           GFD-II
Power supply range                         400 - 500 V, 50 or 60 Hz, 3 phase
Type of mast                                  650, tubular steel with integrated rack
Length mast section                        1.508 m
Weight mast section with 1 rack       118 kg
Rack module                                  5
* Increased travelling speed up to 100 m/min. on request
** Increased lifting height on request. 250 m with step-up transformer only. 400 m with step-up/step-down transformer
