| Model | NGL 16mm | NGL 18mm | NGL 20mm | NGL 24mm | NGL 26mm | NGL 30mm | NGL 36mm | NGL 40mm | NGL 48mm | NGL 60mm |
|---|---|---|---|---|---|---|---|---|---|---|
| Length of Bed | 4900 | 5500 | 6100 | 7300 | 7900 | 9100 | 10970 | 12200 | 14600 | 18300 |
| Width of Bed | 650 | 700 | 750 | 800 | 900 | 1000 | 1050 | 1150 | 1250 | 1500 |
| Height of Center | 600 | 650 | 700 | 750 | 850 | 950 | 1000 | 1100 | 1150 | 1350 |
| Destance Between Center | 2850 | 3450 | 4050 | 5150 | 5750 | 6800 | 8500 | 9600 | 11700 | 15000 |
| Spindle Hollow | 103 | 103 | 103 | 103 | 103 | 103 | 127 | 150 | 150 | 150 |
| Swing Over Saddle (Dia) | 950 | 1050 | 1100 | 1150 | 1400 | 1600 | 1650 | 1850 | 1950 | 2350 |
| Swing Over Bed (Dia) | 1200 | 1300 | 1400 | 1500 | 1700 | 1900 | 2000 | 2200 | 2300 | 2700 |
| Swing Over Gap (Dia) | 1700 | 1800 | 1900 | 2000 | 2200 | 2400 | 2500 | 2700 | 2800 | 3250 |
| No. Of Spindle Speeds | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 |
| RPM Range | 3-85 | 3-85 | 3-85 | 3-85 | 3-85 | 3-85 | 3-85 | 3-85 | 3-85 | 3-85 |
| Lead Screw Dia | 60 | 60 | 60 | 60 | 60 | 75 | 80 | 85 | 85 | 85 |
| Lead Screw Pitch T.P.L | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
| H.P. Recommended | 10 | 10 | 15 | 15 | 20 | 20 | 25 | 30 | 40 | 50 |
