100-200°C 50Hz DC Electric Allen Bradley 1762-if4 Module, Feature : High Performance, Stable Performance





Electrical Resolution of the analogue inputs Input, current Input, voltage Input, resistor Input, resistance thermometer Input, thermocouple Input signal, configurable Output, current Output, voltage Output signal configurable Analogue inputs configurable Analogue outputs configurable Type of electric connection Fast transient burst Conducted immunity Radiated immunity Surge immunity Module power LED

15 Bit

Yes

Yes

No

No

No

Yes

No

No

No

Yes

No

Screw connection

IEC1000-4-4: 2kV, 5 kHz

10V, 0.15...80 MHz

IEC1000-4-3: 10 V/m, 80...1,000 MHz, 80% amplitude modulation, +900 MHz keyed carrier

IEC1000-4-5: 1kV galvanic gun

On: indicates power is applied

Environmental Operating temperature ESD immunity Operating altitude Storage temperature Operating humidity

-20 °C

EN 61000-4-2, 4 kV contact, 8 kV air, 4 kV indirect

2000 m

-40 °C

5...95% noncondensing

Input Specifications Common mode voltage range A/D converter type Number of inputs Common mode rejection Input update time Input impedance Current input protection Voltage input protection Channel diagnostics

-27 to 27V

Successive approximation

4 differential (bipolar)

>55 dB at 50 and 60 Hz

Typical: 130, 250, 290, 450, 530 ms (selectable)

Voltage Terminal: 200 KΩ

-32 mA

-30 V

Over or under range or open circuit condition by bit reporting for analog inputs

General Specifications Analog normal operating range Bus current draw, max Full scale analog ranges Repeatability Input and output group to system isolation

Voltage: -10...10V DC

40 mA @ 5V DC, 50 mA @ 24V DC

Voltage: -10.5...10.5V DC, Current: -21...21 mA

-0.12 to 0.12%

30V AC/30V DC rated working voltage (N.E.C. Class 2 required) (IEC Class 2 reinforced insulation) type test: 500V AC or 707V DC for 1 minute

Construction Height Width Depth Recommended cable

90 mm

40 mm

87 mm

Belden 8761 (shielded), (For 1762-IT4, shielded thermocouple extension wire for the specific type of thermocouple you are using. Follow thermocouple manufacturer’s recommendations.)

Output Specifications Non-linearity Typical overall accuracy

±0.12% (in percent full scale)

±0.32% full scale @ -20...65 °C, ±0.24% full scale @ 25 °C

Mechanical Weight Vibration Shock

Shipping: 240 g (0.53 lbs.) approximately (with cartoon)

Operating: 5 g @ 10...500 Hz, 0.030 in. max. peak-to-peak

Operating: 30 g

Common Specifications Hazardous environment class Radiated and conducted emissions

Hazardous Location, Class I, Division 2 Groups A, B, C, D (UL 1604, C-UL under CSA C22.2 No. 213)

EN50081-2: Class A
