Contact SupplierDin Abrasion Machine :
Alpha Chem is manufactures,exporter & suppliers Din Abrasion Machine.
Din Abrasion Machine : DIN Type Abrasion Tester applies to the abrasion test of resilient material, rubber, tyre, transport belt, synthetic leather. Itâ€Â²s effictive and esay to operate.
Specimens size 16mm, 6-15mm (D)
Fixture load 2.5N
Weight load 2.5N, 5N
Fixture lateral displacement 4.2mm/wheel each lap
Wheel diameter 150mm
Wheel length 460mm
Wheel rotate speed 40rpm
Travel reservations 40m/20m
Abrasion speed 0.32m/sec
Dip angle 3& deg; The angle of the specimen
Back shaft with vertical roller face
Machine Size(L& times; W& times; H)70& times; 30& times; 30cm
Weight 61 KG approx.
Power : AC220V, 3A
