Product Specifications
Teryair Air operated Diaphragm Pumps are designed for simplicity in operation and maintenance, safe for use in explosive environments.
| IMPA Code | 591605 | 591601 | 591602 | 591603 | 591604 | |
| Teryair Part No. | DP12ALN-B | DP25ALN-C | DP40ALN-C | DP50ALN-C | DP75ALN-B | |
| Pump Size | 1/2″ | 1″ | 1 1/2″ | 2″ | 3″ | |
| Standard Casing | Aluminium | |||||
| Suction Lift | Dry | 4″ | 17″ | 18″ | 21″ | 18″ |
| Wet | 30″ | 31″ | 28″ | 31″ | 30″ | |
| Air Inlet NPT | 1/4″ | 1/4″ | 1/2″ | 1/2″ | 3/4″ | |
| Water | Inlet BSP/NPT | 1/2″ | 1″ | 1 1/2″ | 2″ | 3″ |
| Female | ||||||
| Outlet BSP/NPT | 1/2″ | 1″ | 1 1/4″ | 2″ | 3″ | |
| Female | ||||||
| Size | Height | 8.8″ | 11″ | 17.4″ | 26.3″ | 31.9″ |
| Width | 8.2″ | 10.5″ | 15.4″ | 15.9″ | 17″ | |
| Depth | 4″ | 7.3″ | 11.2″ | 13.5″ | 11″ | |
| Weight Ibs | 13 | 26 | 38 | 72 | 116 | |
| Brochure | ||||||
| Manual | ||||||
