Aluminum Wheelchair With Anti-overturn Device -( Y03a-1)

Aluminum Wheelchair with Anti-Overturn Device: Y03A-1
Description:
1. With 7series Aviation-aluminum frame(φ25mm)
2. Front fork use aluminum porous fork can be up-down adjustable in order to achieve on the best condition
3. The rear wheels with Quuick-release device for storage
4. Rear retaining plate can be up-down adjustable according to users' needs
5. Swing away and detachable armrests
6. Rear wheel: 22" fine rear wheels with aluminum hand railing in order to reduce friction for more flexible
7. Wheels and wheelchair has 3 degree Angle, when an eight-lane shape for more flexible and steady
Specification:
Overall width (mm)
600
615
630
645
N.G. (KG)
10.8
11.0
11.2
11.4
Seat depth (mm)
400
420
Folded-up width (mm)
270
Rear wheel (inch)
22
Front wheel (inch)
4
Front seat height (mm)
430(adjustable)
Rear seat height (mm)
410(adjustable)
Seat width (mm)
380
Overall height (mm)
730(adjustable)
Overall length (mm)
840
capability (kg)
125
Notice:
7003-T5 aluminum alloy: the main elements of the aluminum alloy is Al, Zn, Mg. 7 series aluminum its ductility than normal aluminum 6 series by more than 30%. The 7 series aluminum alloy are widely used in aviation aerospace field, the missile aircraft.
