Contact Supplier| MODEL | 1 | 1½ | 2 | 3 | 4 |
| Table | |||||
| Working Table | 1016x227 | 1213x254 | 1270x280 | 1420x304 | 1575x342 |
| Swivel | ±45° | ±45° | ±45° | ±45° | ±45° |
| T Slot Size | 12.7 | 12.7 | 12.7 | 16 | 16 |
| Longitudinal Traverse | 480 | 585 | 635 | 735 | 810 |
| Cross Feed | 177 | 203 | 254 | 300 | 350 |
| Vertical Traverse | 355 | 406 | 510 | 635 | 710 |
| Spindle | |||||
| Spindle Taper | ISO 40 | ISO 40 | ISO 40 | ISO 40 | ISO 40 |
| No. of Spindle Speeds | 6 | 9 | 9 | 9 | 9 |
| Range of Spindle Speeds | 55-225 | 40-575 | 35-700 | 35-700 | 35-700 |
| Standard Arbour | 25.4 | 25.4 | 25.4 | 25.4 | 25.4 |
| Dia of Spindle in Front of Bearing | 70 | 70 | 80 | 90 | 95 |
| Feeds | |||||
| No. of Longitudinal Feeds | 3 | 3 | 3 | 3 | 3 |
| Electricals | |||||
| Main Motor | 1 H.P. | 2 H.P. | 2 H.P. | 3 H.P. | 5 H.P. |
| Coolant Pump | 0.1 H.P. | 0.1 H.P. | 0.1 H.P. | 0.1 H.P. | 0.1 H.P. |
