Haining Sunparl Antenna

Electrical specifications
model spdb-2400-16v60a
frequency range -mhz 2400-2483
gain -dbi 16
vswr ≤1.5
horizontal beamwidth-° 60
vertical beamwidth-° 15
f/b ratio-db ＞25
polarization vertical
impedance -ω 50
maximum input power -w 100
connector n female
mechanical specifications
antenna dimension-mm 450×165×35
weight-kg 1.27
radome material abs
mounting mast diameter-mm ø30~ø50
rated wind velocity-km/h 241.
