Anti Static PVC Floorings

Supply TypeManufacturer, Supplier
Preferred Buyer Location All over the world

XL Holding Group is actively functioning as Manufacturer, Exporter and Supplier of Anti Static PVC Floorings all over the nation and overseas. High quality and performance PVC Floorings are....

View More Details

Send Enquiry

Product Details

XL Holding Group is actively functioning as Manufacturer, Exporter and Supplier of Anti Static PVC Floorings all over the nation and overseas. High quality and performance PVC Floorings are available for you. We can confirm you the high quality and most competitive price.

Product Brief :

Permanent and consistent anti-static function with ESD (Electro-Static discharge) Technology
Highly stain resistant and outstanding wear resistance with UV Coating surface,make for Lower maintenance cost
Excellent in Fire prevention ,moisture proof and anti-corrosion
Uniform size and Multiple options in color with Fade Resistant
Prominent installation performance and workability
Low outgassing emission and dust-free technology

PVC installation guide :

Materials include: Dissipative PVC tile Conductive adhesive Welding rod Copper foil
Main tools include: Grooving machine, plastic welder, rubber hammer, cutting-off tool, ruler, brush, waxing machine, etc.
Ground requirements The basic ground should be clean, dry and flat. The foundation should be cement or terrazzo ground, but couldnot have the phenomenon of sanding and separation. The strength of surface cement can be lower than No.75. The ground should be flat, the unevenness must be less than 2/2000mm or make self-leveling cement ground. If the foundation is formation, the ground must do waterproofing.
Note of installation At installation, the ground residual moisture should not exceed 2.5% (CMDUMB test). The PVC floor, adhesive and job siteâï¿½ï¿½s temperature must keep above 18 degrees Celsius in 24 hours before the installation. High quality conductive adhesive and copper foil must be used in the installation..

Technical Data

Item	Technical Data
THICKNESS EN428	2.0 mm,2.5mm,3.0mm	----
SIZE EN426	600×600mm	610×610mm
WEIGHT EN430	3.8kg/2.0mm,4.8kg/2.5mm,5.8kg/3.0mm	----
ELECTRIC PROPERTIES DIN51953 ASTM F-150 OR NFPA99	CONDUCTIVE TILE	DISSIPATIVE TILE
----	10^410^6 ohm	10^610^9 ohm
DECAY TIME SJ/T10694-20061000V±100V≤2	EQUAL 0.4S	EQUAL 0.4S
CHARGE VOLTAGE SJ/T10694-2006(100V	EQUAL 70	EQUAL 70
FIRE RESISTANCE DIN4102	B1	B1
COMBUSTION PROPERTIES SJ/T11236-200110S, reachFV-0	EQUAL 0FV-0	EQUAL 0FV-0
AMOUNT OF ANTI-WEAR SJ/T11236-2001(≤0.020g/21000r)	EQUAL 0.014	EQUAL 0.014
ANTI-WEAR PROPERTIES EN660pt2	ITEN-Tï2.0mm3	ITEN-Ti2.0mm3
WHEEL PRESSURE EN425	No influence	No influence
RESIDUAL CONCAVITY EN433/DIN51955	0.03mm(2.0 mm) 0.035 mm(2.5 mm) 0.04 mm(3.0 mm)	0.03 mm(2.0 mm) 0.035 mm(2.5 mm) 0.04mm(3.0 mm)
DIMENSIONAL STABILITY EN434	≤0.10%	≤0.10%
COLOR FASTNESS ISO105BO2	At least 6	At least 6
RESISTANCE TO CHENMICALS DIN423/DIN51958	Offers excellent resistance ask for special sheet	Offers excellent resistance ask for special sheet
IMPACT SOUND ABSORPTION VLI,ISO104,ISO717	Approx 2dB	Approx 2dB
STANDARD FOR HEALTH CARE FACILITIES NFPA 99	Confirms to the requirement of NFPA99 ineffect at the tine of installation	----
