API 5ct Oil Tubing

Api 5ct tubing
standard: api 5ct
size: 1.050"- 4 1/2"steel grade: h40,j/k55,n/l80,p110,c90,c95,q125,and ect.
type: nue, eue;
usage:well drilling;
length: r1, r2, r3.
j55 physical properties
y.s. : 379mpa~552mpa
t.s. Min : 517mpa
k55 physical properties
y.s. : 379mpa~552mpa
t.s. Min : 655mpa
n80 physical properties
y.s. : 552mpa~758mpa
t.s. Min : 689mpa
l80 physical properties
y.s. : 552mpa~655mpa
t.s. Min : 655mpa
hardness max : 23hrc
p110 physical properties
y.s. : 758mpa~965mpa
t.s. Min : 862mpa
hardness max : 33hrc
size desination weight desination outside diameter wall thickness type of end finish
grade
t&c non-upset t&c external upset in mm in mm j55 k55 l80 n80 c90 t95 p110
1.900 2.40 - 1.900 48.26 0.125 3.18 pi - - - - -
2.75 2.90 0.145 3.68 pnui pnui pnui pnui pnui -
3.65 3.73 0.200 5.08 pu pu pu pu pu pu
4.42 - 0.250 6.35 - p - p p -
5.15 - 0.300 7.62 - p - p p -
2 3/8 4.00 - 2.375 60.3 0.167 4.24 pn pn pn pn pn -
4.00 4.70 0.190 4.83 pnu pnu pnu pnu pnu pnu
5.80 5.95 0.254 6.45 - pnu pnu pnu pnu pnu
6.60 - 0.259 7.49 p p p p p -
7.35 7.45 0.336 8.53 pu pu pu pu pu -
2 7/8 6.40 6.50 2.875 73.02 0.217 5.51 pnu pnu pnu pnu pnu pnu
7.80 7.90 0.276 7.01 - pnu pnu pnu pnu pnu
8.60 8.70 0.308 7.82 - pnu pnu pnu pnu pnu
9.35 9.45 0.340 8.64 - pu - pu pu -
10.50 - 0.392 9.96 - p - p p -
11.50 - 0.440 11.18 - p - p p -
3 1/2 7.70 - 3.500 88.9 0.216 5.49 pn pn pn pn pn -
9.20 9.30 0.254 6.45 pun pun pun pnu pnu pun
10.20 - 0.289 7.34 pn pn pn pn pn -
12.70 12.95 0.375 9.53 - pun pun pnu pnu pun
14.30 - 0.430 10.92 - p - p p -
15.50 - 0.476 12.00 - p - p p -
17.00 - 0.530 13.46 - p - p p -
4 9.50 - 4.00 101.6 0.226 5.74 pn pn pn pn pn pn
10.70 11.00 0.262 6.65 pu pu pu pu pu pu
4 1/2 12.60 12.75 4.500 114.3 0.271 6.88 pnu pnu pnu pnu pnu -
15.20 - 0.337 8.56 - p - p p -
17.00 - 0.380 9.65 - p - p p -
18.90 - 0.430 10.92 - p - p p -
21.50 - 0.500 12.70 - p - p p -
23.70 - 0.560 14.22 - p - p p -
26.10 - 0.630 16.00 - p - p p -
