Argus Double Side UV Processor

The PC7100 single sided UV curing systems are designed to expose photoimageable materials to intense UV energy. The UV energy is provided by employing medium pressure mercury vapor lamps above the conveyor. Lamp intensities of 200 watts per inch and 300 watts per inch are available with 2 or 3 lamp arrangements. Lamp energy is application dependent, but the standard equipment includes 2 lamps are 200WPI each.
An optional water cooling system is available for exposing products that require a low surface temperature be maintained. The water cooling system supplies an IR filter which consumes IR emissions at the source, thereby reducing effective surface temperatures. The filtration system includes a water jacket type arrangement that provides a wall of water surrounded by two walls of quartz glass. The water is cooled in a self contained cooling system and recirculated in a closed loop fashion.
