ASTM D5882 Low Strain Dynamic Pile Tester

1. Follow the specifications:

ASTM D5882 Standard Test Method for Low Strain Integrity Testing of Piles

JGJ106-2003 (China) Technical code for testing of building foundation piles

2. Parameters::

1). Size: 62 * 172 * 225 mm.

2). Weight: 2.0 kg.

3). High-contrast touch screen display.

4). Temperature range: Operating Range: 0° to 40° C; Storage Range: -20° to 65° C.

5). Powered by internal battery (6 hours duration).

3. Functional:

1). The LPT-E is used for Integrity pile testing and judging defect position

2). Automatic data storage

3). Signal amplification capability

4). Data can be averaged over a variable number of blows.

5). Variable signal amplification over time

6). 24-bit AD converter

7). Sample size: 4k

8). Sample Frequency: 48kHz, 96 kHz,144 kHz
