technicial parameters
material: pe.pp.abs
max container capacity: 220l
output (dry cycle): 280pc/hr
machine dimension(l*w*h): 6.0*3.0*4.9m
total weight: 30ton
clamping force: 900kn
platen opening stroke: 700-1600mm
platen size: 1350*1600mm
max mould size(w*h): 1100*1600mm
mould thickness: 700-1600mm
max drive: 90kw
total power: 112kw
fan power for screw: 0.18*5kw
air pressure: 0.8mpa
average energy consumption: 60kw
motor power for pumps: 22kw
screw diameter: 120mm
number of heating zone: 6zone
extruder heating power: 36kw
extruder driving power: 90kw
number of heating zone: 6zone
power of die heating: 30kw
max die pin diameter: 580mm
accumulator capacity: 25l.
