Technicial parameters
material: pe.pp.abs
max container capacity: 60l
output(dry cycle): 360pc/hr
machine dimension(l*w*h): 5.1*2.5*3.9m
total weight: 12.8ton
clamping force: 350kn
platen opening stroke: 500-1050mm
platen size: 950*900mm
max mould size(w*h): 700*900mm
mould thickness: 460-600mm
max drive: 52kw
total power: 66kw
fan power for screw: 0.18*4kw
air pressure: 0.8mpa
average energy consumption: 26kw
motor power for pumps: 30kw
screw diameter: 90mm
screw l/d ratio: 24
number of heating zone: 4zone
extruder heating power: 21kw
extruder driving power: 37kw
number of heating zone: 4zone
power of die heating: 17kw
max die pin diameter: 350mm
accumulator capacity: 6.6l.
