Automatic Chemical Automatic Chemical Product Packaging Machine

we offer bw-2500c type automatic chemical product gable-top packaging machine is automatic with top configuration. the entire machine is made of food-grade stainless steel, and the surface is special processed to be beautiful.
1. work flow:
put cardboard into carton holder (manually) -- bottom preforming -- bottom heating and sealing -- ultrasonic capping (optional) -- filling -- top preforming -- top heating and sealing -- date printing -- finished product
the whole process is controlled by plc, and only need one person to operate.
2. suitable for filling:
various kinds of sauce, spices, cleaning solution, liquid chemical product, etc
3. technical parameter:
1. capacity: 250--1000ml (can be filled by one machine)
2. output: 1800-2500 cartonshour
3. packing material: cardboard carton aluminium foil carton
4. shelf life: depend on different product and different process
5. capping: with capping (optional)
6. filling temperature: hot filling: 88-92 degc cold filling: 2-50 degc
7. overall power: 25kw (three phases of electricity)
8. compressed air pressure: 1.0-1.4 mpa, flow rate: 1.4-2m3min, without oil, water and dust
9. cooling water: flow volume: no less than 40l min temperature: no higher than 30 degc
10. size: (l*w*h): 3.7m*1.6m*2.8m
11. net weight: 3500kg
12. installation requirement: any smooth floor, such as cement, floor tile, plastic ground, etc. do not need to make angle.
