| Main parameter | MTAEB 500 E | MTAEB 600 E |
| Panel thickness | 10-60mm | 10-60mm |
| Tape thickness | 0.4-3mm | 0.4-3mm |
| Feeding speed | 14/20/23 m/min. | 14/20/23 m/min. |
| Minimum panel length | 150mm | 150mm |
| Minimum panel width | 60mm | 60mm |
| Working pressure | 6-8 bar | 6-8 bar |
| Glue tank capacity | 2kg. | 2kg. |
| Power of end trimming unit | 0.37 kw x 2 | 0.37 kw x 2 |
| Power of top and bottom trimming unit | 0.75 kw x 2 | 0.75 kw x 2 with 18000rpm |
| Power of top and bottom trimming unit 2 | No | 0.75 kw x 2 with 18000rpm |
| Edge scraping unit | Numerical analogue readout | Numerical analogue readout |
| Spraying unit | optional | Optional |
| Buffing unit with cloth disc | 0.37kw x 2 and dia.150mm | 0.37kw x 2 and dia.155 mm |
| Conveyor motor | 2.2kw | 2.2 kw |
| Display | yes | yes |
| Total power | 8kw | 11.5 kw |
| Overall dimension | 4150 x 980 x 1600mm | 5760 x 980 x 1600mm |
| Weight of machine | 1300kg. | 1900kg. |
| Voltage | 415V, 50Hz/ 3-phase | 415V, 50Hz/ 3-phase |
