Automatic Eight Head Bottle Ropp Cap Sealing Machine

Get Latest Price

PhaseSingle Phase
UsageTo Tight & Seal the Caps on Bottles
Support Rod on Existing point of indexing Star wheelStainless Steel 304
Cap Elevator frame (If machine is with Elevator)Stainless Steel 304
Supply TypeManufacturer, Exporter, Supplier
Preferred Buyer Location All over the world

View More Details

Send Enquiry

Company Information

Shree Bhagwati Machtech India Pvt Ltd.

Rakhial, Ahmedabad, Gujarat

View Number

Member Since 10 Years
Nature of Business Manufacturer
GST No. 24AANCS9768F1ZQ

Ask for more detail from the seller

Contact Supplier

Report incorrect details

View Company Details

Product Details
Company Details

PhaseSingle Phase
UsageTo Tight & Seal the Caps on Bottles
Conveyor Length6 Feet Depending upon the product
Elevator BeltPVC
Conveyor ShaftsMild Steel with Hard Chrome or Zinc Plating
BearingsSKF / Nachi / Timken
Capping Head PillarMild Steel with ENP / Hard Chrome
Capping Head VFD Make1 H.P Delta
ModelSBCS-200R
Air PipesSMC / Festo / Janatics
Guide RodStainless Steel 304 (10mm Round Bar)
BowlStainless Steel 304
Sensor MakeSick / Leuze / Panasonic
Compressed Air Required3 H.P Compressor (6 bar pressure 0.5 CFM)
Machine MotionRotary Motion -Index Based
Product Contact PartsStainless Steel 304
Production Speed Per Hour7200 to 9000 Bottles per Hour (Speed Depends up on the size of caps & bottles).
Capping Head Gear Box MakeBonfiglioli Ratio: 20:1
Caps FeedingVibratory Bowl Feeder
Slat Chain Pitch3.5” Stainless Steel 304
“No Cap in Shute Elevator Stop” Sensor (If machine is with Elevator)Panasonic
Speed Synchronization of Star Wheel & Capping HeadVariable Frequency Drive
PneumaticsSMC / Festo / Janatics
Electrical WiringFerrule Numbering on all the wires with Proper Markings
Working Height860 mm (+50 mm)
Guide BracketsSpectra make – Plastic
Machine NameAutomatic Eight Head ROPP Caps Sealing Machines
Non Contact PartsStainless Steel / Mild Steel / Aluminum / Teflon (Whichever is applicable)
Vibrator Pillar MountingMain Platform
Conveyor SlatStainless Steel 304 Slat with Nylon Strips on Side
No Cap in Shute Elevator Stop (If machine is with Elevator)Sensor
Cap Elevator frame (If machine is with Elevator)Stainless Steel 304
Guide Size100mm / 150mm
Capping Head Motor Make1 H.P Bonfiglioli
ShuteStainless Steel 304
Machine DimensionApprox 1830mm (L) x 1220mm (W) x 2440mm (H)
Suitable for ProductsPET / Glass/Aluminum/ HDPE Bottle
Capping UnitRoll Over Pilfer Proof capper designed to thread and seal aluminum cap
Caps HammeringPneumatic System
Wires & CablesLabb
Machine CoveringsComplete in Stainless Steel 304
Up-Down MovementMechanical (Cam System)
Capping UnitStainless Steel .304
Support Rod on Existing point of indexing Star wheelStainless Steel 304
Machine WeightApprox 300 Kgs
Change PartsRequired in case of change in Cap Size & Bottle Size
Control PanelRelay Card (Push Button Type )
Machine PlatformApprox 1210mm (L) x 810mm (W)
Cap Elevator Gearbox Make (If machine is with Elevator)Bonfiglioli Ratio: 20:1
Plating(Wherever Applicable)ENP / Zinc / Hard Chrome / Blackening
ProxyAutonix / Pulset
Vibrator StandMild Steel with ENP Plating
Conveyor SprocketsMild Steel or Nylon
Vibratory Bowl FeederMild Steel Cladded in Stainless Steel 304
Power1 H.P / 230 V.AC
Star Wheel with Back Guide12 mm thick UHMW / Nylon
Electrical ComponentsABB / Delta /Spectra
Cap Elevator Motor Make (If machine is with Elevator)Bonfiglioli
OptionWith Bowl or With Cap Elevator
Machine main frameSquare Pipe, Stainless Steel 304
