Automatic Gas Fired Boiler

We are offering wns szs series automatic oil gas boiler takes biogas, city gas, coke oven gas, natural gas, heavy oil, light oil, diesel, as fuel, is with instant installation and horizontal inner combustion boiler with three strokes, wet backs and fire tubes. The main press components include boiler shell, tube plates, back combustion room, wave hearth, and smoke tube.
The boiler smoke stroke is of three-stroke designs. The first design is structure of wave hearth and back combustion room to enhance the combustion room flexibility. The second stroke is of screwed smoke tube structure to enhance heat transfer and to improve thermal efficiency. The third stroke is of light smoke tube to improve the smoke exhaust temperature and to prevent acid corrosion caused by low exhaust temperature.
The heated surface of the boiler is symmetrical as well as the water cycle. The hot water boiler is in natural cycle mode. Hence the back water flows to the bottom of the cylinder and along the front tube plate cut of the small smoke room, to warm up the water in the boiler. After heating equally, water is exhausted from the top inside the boiler; the heated tube plate of the small smoke room can also be cooled. This layout may reduce stress.
low-position combustion room layout is adopted in addition to the sufficient steam room for the steam boiler. Equipped with efficient equal air hole plate separator, this boiler ensures high steam quality.
Wet-back structure greatly improves the operating environment of the high temperature tube plate. Positive pressure combustion method reduces the heat loss of the smoke exhaust and improves the boiler efficiency.
Press components of the boiler are reliable butt welded line. The boiler shell is made up of 20g boiler steel plate and welded with the front-back tube plates.
