Narrow Fabric Machine, for webbing

Listing ID #2038987

1.95 Lakh / Piece

Get Latest Price

MOQ 1 Piece(s)
TypeAutomatic
Materialms
Applicationwebbing
Place of Originindia
Supply Type Exporter

Preferred Buyer From : All over the world

View More Details

Send Enquiry

Product Details

Type Automatic
Material ms
Application webbing
Brand Name Vishwakarma
Place of Origin india
Model Number vi 2/175
Use garments
Knitted Type weaving
Supply Type 30 days
Warranty 1 year
Width 6 inches
Condition New
Production Capacity as per pick

We wish to introduce ourselves as a leading manufacturer of machinery required for narrow fabrics elastic as well as rigid tape. The machines includes High Speed Needle Loom, Warping machine, Creel for warping machine, Tape finishing machine, Measuring & winding machine ,Aluminum Beam etc.
Vishwakarma Needle Loom:-
Our machines are sturdy and balanced design structure. The machines are supplied in different models. Fabric width wise from 5 mm to 175 mm and nos. of tape 2 to 20 nos. according to width of fabric. All general features like electromagnetic brake, auto stop motion for warp and weft, lock thread weaving systems are provided in our all models.
High speed needle loom with High-performance and specially designed for weaving
Main parameters
1. High speed and stable operation, reach 1,200 R.P.M.
2. Pick-up needle number needle, offers a variety of specifications chooses to use.
3.6/55 add heavy base, high yield, the production of ribbon good quality.
4. Carry arm type structure, durable.
5. Transmission by synchronous belt with loom is linked together, accurate and reliable.
SPECIFICATION AND FEATURES:
MODEL: 2/110 4/65 6/45 6/55 8/35 10/35
TAPES: 2 4 6 6 8 10
WIDTH OF TAPES: 110 65 45 55 32 32
MOTOR: 1 HP Three Phase 960 RPM Motor.
SPEED: 1400 RPM
HEALD FRAME: 14-16 PCS
DESIGN CHAIN CIRCLE: 8-48
WEFT DENSITY: 3.5-36.7 WEFT/CM

Additional Information

Payment Terms D/A, D/P, T/TWestern Union
Port of Dispatch Any
Packaging Details wooden box
Delivery Time 30 days

Interested in this product? Ask for more details & Latest Price from seller

Send Enquiry

Company Details

Vishwakarma industries (an ISO 9001:2008 certified company) is a reputed manufacturer & exporter of textile machinery. We are well known for narrow fabric machines since a decade and widely acclaimed for our international standard products, viz., high speed needle loom, fast knit braiding machine, tape loom, narrow fabric needle loom, warping machine, measuring & winding machines, gauze bandage rolling and cutting machine, aluminum beam, creel stand, beam stand, and special purpose machinery.
products for the following applications can be made from our machines :-
for the manufacture of satin ribbon, elastic tapes, mattress tape plain & design tapes, cotton tapes, twill tape, nylon tapes, elastic bandage, cotton bandage,malai dori, fancy dories, fiber glass tapes, zipper tapes, jute tapes, mono filament tapes, curtain tapes, crepe bandage, hand bag tapes, tapes for identity cards, cotton, jute and mono-filament niwars, safety belts, cargo lifting belts, boarder tapes for saris, elastics & strips for ladies and gents under garments, belts for jumbo bags, laces, labels etc.
our machines are sturdy and balanced design structure. The machines are supplied in different models. Fabric width wise from 5 mm to 175 mm and nos. Of tape 2 to 20 nos. According to width of fabric. Max. Healed frame are 16 nos. Which is enough for general weaves used in elastic as well as rigid tapes. That gives sufficient space for smooth working. All general features like electro magnetic brake, auto stop motion for warp and weft, lock thread weaving systems are provided in our all models. Our standard supply includes system for warp supply through beams.
Our full effort, devoted for customers' satisfaction, starts from their exact need up to commissioning of the machines. We ensure prompt after sales service and understand customers' production program. We are always on a pace of modernization & improvement of our products, based on field feedback, customers' suggestions, requirements and constant effort on r&d.
