Automatic packing machine

The company is the renowned Manufacturer, Exporter and Supplier of highly efficient Automatic Packing Machine. For the manufacturing of our Automatic Packing Machine, we make use of only superior grade parts and components. Owing to attributes like sturdy construction, easy operation and longer service life, our machine is widely in demand. We make available our Automatic Packing Machine at market leading prices.

Scope Of UsesBagging scales are used on the flour / samolina mills to weigh and automatically pack the powdered material with precise screw system. With automatic filling , bag mouth holder, bag vibrator options, requires minimum labor to pack 10-25-50 kg packing options.

• Consists of three main parts :

  • Two-speed screw feeder
  • Regulation of full flow and dribble flow with an electropneumatically controlled flap
  • Electropneumatically controlled stop gate for precision cut-off of product and accurate weighment.


Features And Advatanges :

• Weigh hoper suspended on electronic load cells with
• electopneumatic double flap discharge doors
• Easily accessible doors for inspection and service
• Bag clamp with pneumatic operator
• Electronic control unit with specially designed PLC control
• Accuracies of +/- 50 grams on 50 kg bags can be achieved
• One or two regulation system for customer needs
• Suitable for bagging of materials in open mounth bags
• Accurate and quick weighing with load cells
• Programmable set values with 10 gr intervals
• Programmable desired number of bags
• Seperately programmable high and low tolerance values
• Alarm functions for out of tolerance weighment
• Level control in the regulation bin
• 12-20 ton/hour bagging capacity depending on the product
• Display of total number of bagged and total weighed materials
• Easy and practical calibration
• Alarm function for the faults
• Display of the fault message at the operator terminal
