Automatic Potato Chips Production Line

We are offering automatic potato chips production line.
fried potato chips is popularfried potato chips is a kind of snack processed from fresh potato after washing, peeling, slicing, frying and flavoring.it remains the special delicious flavor of roasted potato on one hand and has the characters of rich nutrition on the other. It is very popular among the customers.
fully automatic potato chips production line descriptionfully potato chips production line is composed of the following continuous process: potatoes cleaning and peeling-picking-cutting-blanching-dewatering-frying-de-oiling-flavoring -packing1. Potato cleaning and peeling is the first step to process potato chips. An elevator is used to transfer potatoes into cleaning and peeling machine. 2. Then this process is picking the well-formed potatoes to be cut into strips. The potato chips machine is reasonably designed with stainless steel blades which ensure even and uniform cutting.3. Blanching is a must-have to preserve authentic flavor which is important in making natural potato chips.4. Frying part needs the relative dried potato strips,the dewatered potato strips are low in moisture and ready to fry.5. During frying, the temperature should be controlled around180 degrees celsius,the potato strips should be fished out when they become golden and soft. 6. De-oiling makes potato chips more healthy and palatable. 7. In this step, you can season whatever flavor you like onto the potato chips.8. The last step is to pick the uniform potato chips and package them for sale.
fully automatic potato chips production line characteristics1. We can customize different processing capacity for you.2. All the machines are made of stainless steel.3. The whole line just needs 1 person to operate, labor and cost saving.4. Low investment, low energy consumption and no noise.
automatic potato chips production line technical data
no. equipment power dimension
1 elevator 0.75kw/380v/50hz 2400x670x2150mm
2 potato washing& peeling machine 4.75kw/380v/50hz 2300x1000x1200mm
3 potato picking line 0.75kw/380v/50hz 6000x800x800mm
4 elevator 0.75kw/380v/50hz 2400x670x2150mm
5 potato chips machine 1.5kw/380v/50hz 1000x800x1600mm
6 potcher 1.1kw/380v/50hz 6000x1000x1600mm
7 blancher 60kw/380v/50hz 6000x1000x1600mm
8 dewatering machine 7.5kw/380v/50hz 6000x1100x1500mm
9 frying line 140kw/380v/50hz 7000x1000x2000mm
10 de-oiling line 7.5kw/380v/50hz 6000x1100x1500mm
11 flavoring 1.1kw/380v/50hz 4000x850x2100mm
12 picking and choosing line 0.75kw/380v/50hz 6000x800x800mm
13 packing machine 6kw/380v/50hz 1425x720x950mm
