Automatic Pressure Portable Sand Blast Equipment

We offer automatic pressure portable sand blast equipment.
Blast room construction
our blast rooms are constructed from eps panel and lined with 3mm insertion rubber on the walls and doors. The room will be fitted with one pa door at the opposite end to the double entry doors. Lighting consists of 320 watt lights mounted in the ceiling.
Abrasive recovery & classifier system
this combination unit is specifically designed for abrasive media reclaiming and recycling. Media is collected at floor level in the under floorscrew conveyors which deliver the spent media to the boot (base) of the bucket elevator. The buckets lift the abrasive to the top of the bucket elevator and discharge it through a chute to the in feed of the air wash separator which is adjustable to suit all media from steel shot to garnet sand. Connected to the air wash is a dedicated dust collector. The ventilation airflow is used to pull the fine dust from the curtain of the air wash. Dust is collected, reverse pulsed cleaned from the cartridges and deposited in the dust collector drum. Dust free media is gravity fed through a screen to remove coarse trash, cleaned recycled media is then stored in the media storage hopper ready for recharging to the blast vessel.
Screw conveyor
steel grit or garnet media is collected in troughs installed beneath the blast room floor positioned down each side of the blast room. A cross screw conveyor set in a trench transports the abrasive media across the blast room to the boot of the bucket elevator. The troughs incorporate a grate and screen to protect the screw conveyors and bucket elevators from large foreign objects. The media is fed to the bucket elevator.
